Browning BAR Picatinny Rail
Browning BAR Picatinny Rail
Couldn't load pickup availability
This Picatinny rail fits:
Browning BAR
Benelli ARGO
Benelli R1
Browning BLR Long Action
Browning BLR Lightning Long Action
Browning BAR MK2
Browning BAR MK3
Browning Maral
Specifications:
| Manufacturer HG Firearms is the manufacturer of this picatinny rail. Read more | HG Firearms |
| Material The material affects weight, durability, and application. Read more | Steel |
| Surface QPQ is a surface treatment that increases wear resistance and corrosion resistance. Read more | QPQ-treated |
| MOA MOA indicates the rail's incline and can provide more elevation adjustment in the scope. Read more | 0 and 10 MOA |
| Screws | 6-48 Leupold TORX, included |
| A/B/C dimensions A/B/C dimensions are used to check hole spacing and fit before purchase. Read more | 12.70 / 81.00 / 12.70 mm |
| Length | 155 mm |
Which MOA should you choose?
Choose 0 MOA for a neutral mount. Choose 10 MOA if you need more elevation adjustment in your scope.
Mounting
Ensure that the holes in the receiver, screw threads, and contact surfaces are clean before mounting. Place the Picatinny rail so that the holes align with the holes in the receiver, and tighten the screws according to the manufacturer's recommendations. Optionally, use a small amount of suitable thread locker, and remove any excess oil or thread locker before use.
See guide for mounting Picatinny rail
This package includes
1 pc. Picatinny rail and 6-48 Leupold TORX screws.
